HVP-40 High Voltage Probe

Before taking any measurements, connect the alligator clip to this probe to earth ground and make sure the connection is electrically good. Input impedance: Approx. 1000MΩ Division Ratio: 1000: 1 MAX. Test Voltage DC : 0 ~ 40KV AC : 1 ~ 28KV ( 50 / 60 Hz ) Safety APPL. EN61010 UL3111-1 TUV / GS IEC 1010 CAT II Pollution 2 Polarity: Positive / Negative Accuracy DC:+/- 1% to 20KV，+/- 2 % to 40KV AC : - 5 % to - 10 % ( 1 ~ 28KV ; 50 / 60Hz ) Temperature Coefficient:<= 200PPM/℃ Maximum loading Current:<= 40μA ( at 40KV DC ) Maximum loading power:<= 1.6 watt Operating temperature:0 ~ + 50℃ Storage temperature:- 20 ~ + 70℃ Ground Lead length:90cm ( 3ft ) Output cable length:100cm ( 3.3ft ) For: DMM Output Division:1V / 1KV Dimensions:340mm x 80 Φ Weight: about 300g Remark: For 10MΩ input impedance DMM ( Accuracy <0.5 % ) only.

• Attenuation ratio: 1000:1. It must be used in conjunction with a power meter with an input impedance of 10MΩ. Meter output indication: X1000 bit, i.e., 1V→1000V; 10V→10KV
• Input impedance: Approx. 1000 MΩ
• MAX. Test Voltage. DC : 0 ~ 40KV. AC : 1 ~ 28KV ( 50 / 60 Hz )
